Alfain Svarog 320 HD PULSE Modular MIG/MAG welding machine
Industrial welding machines ALFA IN!
The perfect solution for even the most demanding welding jobs
The demands in the field of manual welding are often very high, the welding equipment must enable the achievement of exceptional quality of the weld joint and efficient operation. The machines must be variable, ergonomic, reliable, long-lasting and serviceable. The perfect answer to all these challenges are ALFA IN industrial welding inverters, which use the latest technology with the highest level of quality, offer economical operation, energy efficiency and a durable construction for tough conditions. The digital control of the source ensures an extremely stable arc that guarantees excellent welding results. Simple and intuitive operation makes everyday work easier. All ALFA IN welding inverters are innovative and powerful solutions, with which you can handle any welding work. Whether it is welding with a coated electrode, the MIG/MAG or TIG method, ALFAIN a.s. , as one of the leading manufacturers in the field of welding technology, offers the ideal solution for every welding process. Welding inverters are used in metalworking operations for light and heavy structures, in repairs, maintenance in service and automotive workshops, in the production of industrial equipment and in educational institutions. The quality and performance provided by ALFA IN welding machines are chosen by users all over the world.
WELDING MACHINES FOR HIGH PERFORMANCE AND A WIDE RANGE OF APPLICATIONS!
Made in Czech Republic!
We are traditional manufacturers of welding technology and cutting technology in the Czech Republic
SVAROG 320 HD PULSE modular is a 320A welding machine with a wide range of applications:
• For MIG/MAG welding, where it is possible to choose manual, synergic and pulse welding process
• Excellent welding properties in mixed gas and CO2
• Wire Ø 0.6 – 0.8 mm, or 1.0 – 1.2 mm from various metal materials and alloys (carbon and alloy steels, aluminium alloys, zinc, etc.)
• Smooth voltage regulation
• Pre-gas, post-gas, burn back and initial wire speed regulable
• Enables welding with tubular wire (watch out for polarity reversal)
• 4 rollers wire feed, electronic choke, ecological cooling mode
• Modular concept
• Lighting of the interior space of the feeder
• Front braked wheel
• Optional liquid cooling and many other accessories and functions
• Czech prices for spare parts and service work
WHY SVAROG?
Modular machines SVAROG 320 HD PULSE modular brings you a new concept that will help you handle demanding welding work. The concept of modularity allows the machine to be configured according to current needs
• A simple small chassis with no space for a gas bottle
• Robust and elaborate chassis with space for transporting a gas cylinder
• Robust and sophisticated chassis with the option of a practical pull-out storage box or a cooling unit
• The option of easily adding a cooling unit for heavy jobs Advantages of the modular concept
For demanding jobs, for example in the field, you can easily and quickly disconnect the welding inverter itself from the chassis, or the liquid cooling of the welding torch. You immediately have a light, compact welding power source with a power of 320A. The stand-alone welding source weighs only 31.7 kg.
How do you dismantle it all easily and quickly?
Using solid metal locks that you open without the use of tools!
If you choose a robust chassis with a pull-out storage box, you have everything you need immediately available. In a spacious and easily accessible pull-out box, you can store gloves, tools, consumables for the torch or electrodes for the MMA method.
Low acquisition costs!
You don't have to immediately spend money on the purchase of a machine with liquid cooling for the torch. A big advantage of the SVAROG 320 HD PULSE modular modular concept is the possibility to supplement the machine with liquid cooling at any time and without the need for a specialist workshop. You can easily connect using basic tools and prepared connecting material (which is part of the supplied cooling kit). A control connector is provided as standard on the source, which you simply connect.
Economy and sustainability!
Inverter technology ensures low power consumption at a constant output power and thus reduces electricity consumption.
Efficiency 89%
According to standardised measurement methods, Svarog achieves 89% efficiency. This means that a large part of the power input from the mains is converted into arc energy without loss.
Cooling
ACL-10 coolant achieves exceptional sustainability due to its composition and extends the life of the system.
Filter!
In the basic equipment, a filter is placed in the cooling circuit, which captures any impurities. It protects the entire cooling system and the welding torch, is easy to check and can be repeatedly cleaned.
Easy JOBs setup!
Direct storage of 6 JOBs by long holding the button and direct recall of JOBs by short pressing of the button. We reserved a separate button for each JOB out of 6. Calibration of the welding circuit The welding properties of the synergic curve depend on many factors, such as the length of the welding torch, the length of the grounding cable, the quality of the grounding, the distance of the weldment from the grounding point, etc. Therefore, it is advisable to calibrate the welding circuit for the current welding conditions. The function of calibration of the welding circuit will make it possible to eliminate these effects.
EASY PULSE mode setup!
With just one push of a button, everything is set for pulse welding mode…
70% less finishing work!
Thanks to the pulse function, it is possible to avoid the difficult-to control transition arc, which is loaded with high spatter.
Less welding spatter generation reduces finishing work by up to 70%.
A large selection of synergistic programs!
Steel SG/Fe, Cr/Ni, AlSi, AlMg, wire diameters 0.8; 1.0; 1.2 mm various gas mixtures
Illumination of the interior space of the wire feeder.
A strong LED diode effectively illuminates the interior space and ensures easy replacement of the wire in poor light conditions.
Technical data
SVAROG 320 HD PULSE MODULAR
Method MIG/MAG MMA
Mains voltage V/Hz 3x400/50-60
Welding current range A/V MIG/MAG 30 - 320; MMA 20 - 300
Open-circuit voltage U0 V 60
Mains protection A 16 @
Max. effective current I1eff A 15,1
Welding current (DC=100%) I2 A 240 200
Welding current (DC=60%) I2 A 280 240
Welding current (DC=x%) I2 A 35%=320 30%=300
Insulation class IP 23S
Standards EN IEC 60974-1, EN 60974-10 cl. A
Dimensions mm 534 x 1141 x 943
Weight with cooling kg 84
Weight without cooling kg 77
Maximum load of the pull-out storage box kg 25
Weight without chassis kg 31,7
Wire speed m/min 1,0 - 20,0
Spool diameter mm 300 (15-18kg)
Spool weight kg max 18
Cooling power (Q=1l/min) kW 0,8
Total liquid content l 4,0
Max. pressure Bar 3,5
Max. flow l/min 8,0
*the device consists of modules. This kit is standard without carts and cooling module
ALFAIN SVAROG-320-HD-PULSE-modular-prospekt-EN.pdf
