Welding machine ALFAIN aXe 230 MIG MAN-4 inverter for MIG/MAG welding
Welding machine ALFAIN aXe 230 MIG MAN-4 inverter for MIG/MAG welding.
Code E.144
Excellent welding properties in mixed gas and CO2 environments;
Welding of various metals and alloys (carbon and alloy steel, aluminum, etc.) with wire with a diameter of 0.6 - 0.8 mm or 1.0 - 1.2 mm
Constant voltage level support;
Adjustable Burn Back;
4 wire feed rollers;
Electronic ignition control;
Top wire feeder class - four-roller feed with large rollers and incremental encoder ensures safe and reliable wire feeding
TECHNICAL DATA
Mains voltage: 3x 400 V
Mains frequency: 50 / 60Hz
Max. no-load voltage: 76V
Fuse [MIG-MAG]: 16 A
Welding current range [MIG-MAG]...: 30 - 230A
Welding current [MIG-MAG] (DC=x%)..........: 230@60%
Voltage settings: constant
Insulation class: F
Protection class: IP23S
Standards: EN 60974-1, EN 60974-10 cl.A
Dimensions: 474 x 911 x 670 mm
Weight: 49kg
------------------------------------------------
Spool diameter ..................: 300 mm
Spool weight ........................: 18 kg
The set includes:
VM0023 Earthing cable 3m 35-50 300A
* Before placing an order, check availability.
